The Chamunda Multi layer press is designed for producing tablets with up to three separate layers single rotary tableting machine. It complies with cGMP norms and can be connected online to devices like Tablet De-dusters and Metal detectors.
71,040 Tab / hr*
,
,
Key highlighted features that can be effective for your requirement.
| MODELS | CPMMLP-31 | CPMMLP-37 |
|---|---|---|
| No. of Stations | 31 | 37 |
| Tooling | “D” | “B” |
| Max Output (Tab/hr)* | 59,520 | 71,040 |
| Max. Pressure | 10 Ton | 6.5 Ton |
| Pre Compression | 1 Ton | 1 Ton |
| Upper Punch Penetration | 3 to 6 mm | 3 to 6 mm |
| Max Tablet Dia. | 25 mm | 16 mm |
| Depth of Fill available for | 415V, 3Ø, AC, 50HZ | |
| 1st layer | 1 to 7 mm | 1 to 7 mm |
| 2nd layer | 1 to 11 mm | 1 to 11 mm |
| 3rd layer | 1 to 15 mm | 1 to 15 mm |
| Main Motor | 3 HP | |
| Force Feeder | 0.25 HP | |
| Electrical supply** | 4.25 HP, 3Ø, AC | |
Chamunda Pharma Machinery Pvt. Ltd. has built a robust global footprint by delivering high-performance roll compactor machines to clients in more than 40 countries.
Our focus on precision engineering, adherence to international quality standards, and dependable after-sales service has positioned us as a preferred partner for pharmaceutical manufacturers across the globe.
Similar application range of technological advanced machineries
Achieve mass production with double-sided rotary tablet press with advanced features, prioritizing safety, ease of operation, and quick tool/product changeovers.
Capacity
439,200 Tab / hr*
,
The sturdy GMP square model double rotary tablet press is designed for medium batch production, featuring high tonnage with various features.
Capacity
226,800 Tab / hr*
,
,
In the entry-level segment of Double Rotary Tablet Press, Proven model with the advantage of Front Control Operations.
Capacity
226,800 Tab / hr*
, ,
